Eaton PLSM-C6/1N-MW LS-Schalter 6A/1pol+N/C 242266
zoom_out_map
chevron_left chevron_right

Eaton PLSM-C6/1N-MW LS switch 6A/1pol+N/C 242266



Trigger characteristic
C
Number of poles (total)
2
Number of secured poles
2
Rated current
A6
Measurement voltage
V230
Measurement switching capacity Icn according to EN 60898 at 230 V
KA10
Measurement switching capacity Icn according to EN 60898 at 400 V
KA10
Measurement switching capacity Icu according to IEC 60947-2 at 230 V
KA0
Measurement switching capacity Icu according to IEC 60947-2 at 400 V
KA0
Type of voltage
AC
Energy limiting class
3
Frequency
HZ50 to 60
Interconnecting neutral conductor
yes
Suitable for underground installation
no
Overvoltage category
3
Pollution
2
Width in division units
1.5
Installation depth
mmANNEX
Additional equipment possible
yes
Type of protection (IP)
IP20
€16.80 VAT included €14.00 (VAT excl.)
VAT included
check 2-5 days
